Grey Galvanized Steel Armoured Cable , Domestic Industrial Armoured Flexible Cable

: Large Image : Grey Galvanized Steel Armoured Cable , Domestic Industrial Armoured Flexible Cable

Product Details:

Place of Origin:	CHINA
Brand Name:	UNI-CABLES
Certification:	CCC,ISO9001
Model Number:	6242Y

Payment & Shipping Terms:

Minimum Order Quantity:	100 Rolls
Price:	US$0.12-2.5 per Meter
Packaging Details:	100 Meters per Roll
Supply Ability:	10000 Rolls per Week

Contact Now

Detailed Product Description

Voltage Rating (Uo/U):	300/500V	Temperature Rating:	-5°C To +70°C
Short Circuit:	+160°C	Minimum Bending Radius:	X Overall Diameter
Sheath Colour:	Grey	Conductor:	4mm² To 16mm²: Class 2 Stranded Conductor
Insulation:	PVC (Polyvinyl Chloride)	Sheath:	PVC (Polyvinyl Chloride)

BS 6004 Cable Fixed Wiring Cable Type 624Y Twin and Earth PVC Cable

Grey Galvanized Steel Armoured Cable , Domestic Industrial Armoured Flexible Cable

APPLICATION

Domestic wiring cable. Can be installed in fixed installations

in dry or damp premises clipped to surface, on trays or in free air where the risk of mechanical damage would not be an issue. Suitable for laying in conduit or trunking where mechanical protection is required.

CONSTRUCTION

Conductor

Copper conductor according to BS EN 60228 (previously BS 6360)

1mm² to 2.5mm²: Class 1 solid conductor 4mm² to 16mm²: Class 2 stranded conductor

Circuit Protection Conductor (Earth)

1mm² to 2.5mm²: Class 1 solid copper conductor 4mm² to 16mm²: Class 2 stranded copper conductor

Insulation

PVC (Polyvinyl Chloride) Type TI1 according to BS EN 50363

Sheath

PVC (Polyvinyl Chloride) Type 6 according to BS 7655

CABLE STANDARDS

BS 6004 Table 4

CHARACTERISTICS

Voltage Rating (Uo/U) 300/500V

Temperature Rating

-5°C to +70°C

Short Circuit : +160°C

Minimum Bending Radius

Fixed: 6 x overall diameter

DIMENSION

UNIQUE PART NO.	NO. OF CORES	NOMINAL CROSS SECTIONAL AREA	CONDUCTOR CLASS	CROSS SECTIONAL AREA OF EARTH CONDUCTOR	NOMINAL THICKNESS OF INSULATION	NOMINAL THICKNESS OF SHEATH	NOMINAL OVERALL DIMENSIONS	NOMINAL WEIGHT
		mm²		mm²	mm	mm	mm	kg/km
UNBVVB2X1WG	2	1	1	1	0.6	0.9	4.35 x 7.95	68
UNBVVB2X1.5WG	2	1.5	1	1	0.7	0.9	4.85 x 8.9	87
UNBVVB2X2.5WG	2	2.5	1	1.5	0.8	1	5.65 x 10.65	120
UNBVVB2X4WG	2	4	2	1.5	0.8	1	6.3 x 11.95	172
UNBVVB2X6WG	2	6	2	2.5	0.8	1.1	7.1 x 13.7	235
UNBVVB2X10WG	2	10	2	4*	1	1.2	8.7 x 17.25	373
UNBVVB2X16WG	2	16	2	6*	1	1.3	9.85 x 20	530
UNBVVB3X1WG	3	1	1	1	06	0.9	4.35 x 9.8	91
UNBVVB3X1.5WG	3	1.5	1	1	0.7	0.9	4.85 x 11.2	115

CONDUCTORS

Class 1 Solid Conductors for Single Core and Multi-Core Cables

NOMINAL CROSS SECTIONAL AREA mm²	MAXIMUM RESISTANCE OF CONDUCTOR AT 20ºC
NOMINAL CROSS SECTIONAL AREA mm²	Plain Wires ohms/km
1	18.1
1.5	12.1
2.5	7.41

Class 2 Stranded Conductors for Single Core and Multi-Core Cables

NOMINAL CROSS SECTIONAL AREA mm²	MINIMUM NO. OF WIRES IN CONDUCTOR	MAXIMUM RESISTANCE OF CONDUCTOR AT 20ºC
	MINIMUM NO. OF WIRES IN CONDUCTOR	Annealed Copper Conductor
	Circular	Plain Wires ohms/km
4	7	4.61
6	7	3.08
10	7	1.83
16	7	1.15

ELECTRICALCHARACTERISTICS

Current Carrying Capacity and Voltage Drop

NOMINAL CROSS SECTIONAL AREA mm²	REFERENCE METHOD A* (IN CONDUIT IN WALL) Amps	REFERENCE METHOD C* (CLIPPED DIRECT) Amps	VOLTAGE DROP mv/A/m
1	11.5	16	44
1.5	14.5	20	29
2.5	20	27	18
4	26	37	11
6	32	47	7.3
10	44	64	4.4
16	57	85	2.8

Note

A* For full installation method refer to Table 4A2 Installation Method 2 but for flat twin and earth cable of the 17th Edition of IEE Wiring Regulations.

C* For full installation method refer to Table 4A2 Installation Method 20 but for flat twin and earth cable of the 17th Edition of IEE Wiring Regulations.
