PVC Black H05VV5 - F Size Flexible Control Cable 12G1 . 0 To 61G1 . 5 Oil Resistant

China PVC Black H05VV5 - F Size Flexible Control Cable 12G1 . 0 To 61G1 . 5 Oil Resistant supplier

Large Image :  PVC Black H05VV5 - F Size Flexible Control Cable 12G1 . 0 To 61G1 . 5 Oil Resistant

Product Details:

Place of Origin: CHINA
Brand Name: UNI-CABLES
Certification: CCC,ISO9001
Model Number: H05VV5-F

Payment & Shipping Terms:

Minimum Order Quantity: 1000 Meters
Price: Negotiable
Packaging Details: 100 meters per roll, or 1000 meters per reel
Supply Ability: 10000 per Week
Contact Now
Detailed Product Description
Voltage Rating: 300/500V Temperature Rating: Fixed: -40°C To +70°C Flexed: -7°C To +70°C
Minimum Bending Radius: Flexed: 7.5 X Overall Diameter Sheath Colour: Black
Conductor: Class 5 Flexible Copper Conductor Insulation: PVC TI2

H05VV5-F European Flexible Control Cable Oil Resistant and Number Coded



APPLICATION

These cables are used for flexible use for medium mechanical stresses with free movement without tensile stress or forced movements in dry, moist and wet rooms but are not suitable for open air. These are designed as control and connecting cables to machines, tool machineries, conveyor belts and production lines.





Conductor material: bare copper

Conductor class: class 5 = fine stranded

Insulation: PVC TI2

Sheathing material: PVC TM5



H05VV5-F are not affected by the chemical influences. Cables for moist and wet rooms, specially used for machines in breweries, bottling plants and car washing stations.


H05VV5-F may be allowed to move once installed provided that the cables are not mechanically stressed during movement.





  •  Control cable, special PVC with oil resistant outer jacket to DIN VDE 0281 part 13, HD 21.13S1 and IEC 60227/75
  •  Temperature Range
    Flexing
    -5°C to +70°C (+23°F to +158°F)
    Fixed Installation
    -40°C to +70°C (-40°F to +158°F)
  •  Nominal Voltage U0/U 300/500 V
  •  Test Voltage 2000 V, 5 min.
  •  Breakdown Voltage min. 4000 V
  •  Insulation Resistance
    Min. 20 MOhm x km
  •  Minimum Bending Radius
    Flexing 7.5x cable Ø
    Fixed Installation 4x cable Ø
  •  Radiation Resistance
    Up to 80x106 cJ/kg (up to 80 Mra







Description & No. Conductors x cross-sec. mm2 Outer Diameter Copper Weight Weight AWG
mm kg/km ca. kg/km
HO5VV5-F 12G1 11.8-14.6 115 269 17
HO5VV5-F 14G1 12.7-15.6 134 361 17
HO5VV5-F 18G1 14.0-17.2 173 400 17
HO5VV5-F 19G1 14.3-17.6 183 413 17
HO5VV5-F 25G1 16.8-17.6 240 546 17
HO5VV5-F 27G1 17.0-21.0 259 582 17
HO5VV5-F 34G1 19.2-23.6 326 724 17
HO5VV5-F 36G1 19.4-23.8 348 775 17
HO5VV5-F 37G1 19.8-24.5 355 785 17
HO5VV5-F 41G1 20.8-25.5 392 822 17
HO5VV5-F 50G1 22.9-28.0 480 1052 17
HO5VV5-F 61G1 24.3-29.8 586 1265 17
HO5VV5-F 65G1 26.5-3.27 624 1315 17
HO5VV5-F-OZ 2X1.5 6.8-8.6 29 77 16
HO5VV5-F 3G1.5 7.4-9.4 43 97 16
HO5VV5-F 4G1.5 8.2-10.2 58 128 16
HO5VV5-F 5G1.5 9.1-11.4 72 149 16
HO5VV5-F 6G1.5 10.2-12.6 86 196 16
HO5VV5-F 7G1.5 11.3-14.1 101 216 16
HO5VV5-F 8G1.5 12.5-15.5 115 271 16
HO5VV5-F 9G1.5 12.9-16.1 130 282 16
HO5VV5-F 12G1.5 13.8-17.0 173 324 16
HO5VV5-F 14G1.5 14.3-18.0 202 372 16
HO5VV5-F 18G1.5 16.5-20.3 259 485 16
HO5VV5-F 19G1.5 16.2-20.0 274 495 16
HO5VV5-F 25G1.5 20.8-25.6 360 671 16
HO5VV5-F 27G1.5 20.3-24.9 389 695 16
HO5VV5-F 32G1.5 21.4-26.4 461 820 16
HO5VV5-F 34G1.5 23.1-28.8 490 881 16
HO5VV5-F 36G1.5 23.0-28.2 518 905 16
HO5VV5-F 37G1.5 23.0-28.2 532 920 16
HO5VV5-F 41G1.5 24.3-29.8 590 1085 16
HO5VV5-F 50G1.5 27.7-34.1 720 1381 16
HO5VV5-F 61G1.5 29.6-36.3 878 1640 16
HO5VV5-F 65G1.5 30.4-37.2 963 1730 16
HO5VV5-F-OZ 2X2.5 8.4-10.6 48 110 14
HO5VV5-F 3G2.5 9.2-11.4 72 154 14
HO5VV5-F 4G2.5 10.1-12.5 96 212 14
HO5VV5-F 5G2.5 11.2-13.9 120 242 14
HO5VV5-F 7G2.5 13.6-16.8 168 350 14
HO5VV5-F 8G2.5 14.9-18.7 192 379 14
HO5VV5-F 12G2.5 16.8-20.6 288 543 14
HO5VV5-F 14G2.5 17.5-22.1 336 611 14
HO5VV5-F 18G2.5 20.2-24.8 432 787 14
HO5VV5-F 25G2.5 24.6-3.2 600 1175 14
HO5VV5-F 27G2.5 24.7-30.2 648 1280 14
HO5VV5-F 34G2.5 27.9-34.1 816 1529 14
HO5VV5-F 36G2.5 28.0-34.2 864 1791 14
HO5VV5-F 41G2.5 30.3-36.9 984 1905 14
HO5VV5-F 50G2.5 33.0-40.5 1200 2290 14
HO5VV5-F 61G2.5 35.0-42.9 1464 2724 14
