Voltage Rating: | 450/750V | Temperature Rating: | 90°C |
---|---|---|---|
Minimum Bending Radius: | 4 X Cable OD | Conductor: | Class 2 Copper Conductor |
Insulation: | V90 PVC | Sheath: | 3V 90 PVC |
Flat TPS 3 Core and Earth PVC Insulated Air Conditioning Cable Voltage 450/750V
Application
These cables are used for general wiring, unenclosed, enclosed in conduit, buried direct or in underground ducts for domestic, commercial and industrial installations where not subject to mechanical damage. Suitable for balanced three phase applications with E.
Mainly for indoor use air conditioner.
Cable Standard
AS/NZS 5000.2,
AS 1125, AS 3808
Cable Construction
Conductor: Plain annealed copper
Maximum continuous operating temperature: 90°C
Insulation: V-90 PVC
Colours:Red, White, Blue, Green/yellow
Sheath: 3V-90 PVC
Colours: White, other colors are available upon request
Cable Parameter
Cable description | Nominal conductor area mm2 | Approx. overall diameter mm |
Approx. mass kg/100 m | Min. installed bending radius mm |
Cores construction/ Sheat colour |
3C+E | 3C+E | 3C+E | 3C+E | ||
Applications: 3 phase | |||||
1.5 3Core and Eearth Flat | 1.5 | 12.8 x 4.6 | 12 | 20 | Red-White-Blue/Blue |
2.5 3Core and Eearth Flat | 2.5 | 15.8x5.5 | 19 | 20 | Red-White-Blue/Blue |
Applications: fixed installations | |||||
1.5 3Core and Eearth Flat | 1.5 | 12.8 x 4.6 | 12 | 20 | Red-White-Black/Blue |
2.5 3Core and Eearth Flat | 2.5 | 15.8x5.5 | 19 | 20 | Red-White-Black/Blue |
