H03VVH2 F Twin Flat Cable Armored Cable Wiring Polyvinyl Chloride For General Use

: Large Image : H03VVH2 F Twin Flat Cable Armored Cable Wiring Polyvinyl Chloride For General Use

Product Details:

Place of Origin:	CHINA
Brand Name:	UNI-CABLES
Certification:	CCC,ISO9001
Model Number:	H05V2V2-F

Payment & Shipping Terms:

Minimum Order Quantity:	100 Rolls
Price:	Negotiable
Packaging Details:	100 Meters per Roll
Supply Ability:	10000 Rolls per Week

Contact Now

Detailed Product Description

Voltage Rating (Uo/U):	300/500V	Temperature Rating:	0°C To +90°C
Sheath Colour:	White	Conductor:	Class 5 Flexible Copper Conductor
Insulation:	PVC (Polyvinyl Chloride)	Sheath:	PVC (Polyvinyl Chloride)

H05V2V2-F PVC Electrical Cable Heat Resistant Flexible Copper Conductor Cable

APPLICATION
H05V2V2-F Heat resistant cables suitable for uses in domestic environments, kitchen, offices, as well as power supply cords of household appliances that are undergone by medium mechanical abuses (washing-machines, hair-dryers, refrigerators). Also, they can be used for heating devices provided they are not in direct touch with hot surfaces or exposed to thermal irradiation. They are not suitable for outdoor use, industrial or agricultural workshops and non-domestic devices.

CONSTRUCTION
Conductor

Class 5 flexible conductor with electrolytic bare or tin-plated copper conforming to IEC 60228

Insulation

Insulation with special PVC with high thermal stability, TI3 type conforming to EN 50363-3 requirements.

Sheath

Outer sheath with special PVC with high thermal stability, TM3 type conforming to EN 50363-4-1

CABLE STANDARDS
BS EN 50525-2-11 (previously BS 6500, BS 7919 table 41),
BS EN/IEC 60332-1-2

DIMENSIONS

UNIQUE PART NO.	NO. OF CORES	NOMINAL CROSS SECTIONAL AREA	NOMINAL THICKNESS OF INSULATION	NOMINAL THICKNESS OF SHEATH	NOMINAL OVERALL DIAMETER	NOMINAL WEIGHT
UNIQUE PART NO.	NO. OF CORES	mm²	mm	mm	mm	kg/km
H05V2V2-F2X0.75	2	0.75	0.6	0.8	6.3	63
H05V2V2-F3X0.75	3	0.75	0.6	0.8	6.7	74
H05V2V2-F3X1	3	1	0.6	0.8	7	86
H05V2V2-F3X1.5	3	1.5	0.7	0.9	8.1	115
H05V2V2-F3X2.5	3	2.5	0.8	1	9.7	170
H05V2V2-F4X0.75	4	0.75	0.6	0.8	7.3	78
H05V2V2-F4X1	4	1	0.6	0.9	7.9	110
H05V2V2-F4X1.5	4	1.5	0.7	1	9	140
H05V2V2-F4X2.5	4	2.5	0.8	1.1	10.8	210
H05V2V2-FX0.75	5	0.75	0.6	0.9	8.1	105

CONDUCTORS
Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables

NOMINAL CROSS SECTIONAL AREA mm²	MAXIMUM DIAMETER OF WIRES IN CONDUCTOR mm	MAXIMUM RESISTANCE OF CONDUCTOR AT 20oC
NOMINAL CROSS SECTIONAL AREA mm²	MAXIMUM DIAMETER OF WIRES IN CONDUCTOR mm	Plain Wires ohms/km	Metal-Coated Wires ohms/km
0.75	0.21	26	26.7
1	0.21	19.5	20
1.5	0.26	13.3	13.7
2.5	0.26	7.98	8.21

ELECTRICAL CHARACTERISTICS
Current Carrying Capacity and Mass Supportable

NOMINAL CROSS SECTIONAL AREA mm2	CURRENT CARRYING CAPACITY		MAXIMUM MASS SUPPORTABLE BY TWIN FLEXIBLE CORD
NOMINAL CROSS SECTIONAL AREA mm2	Single-Phase AC Amps	Three-Phase AC Amps	MAXIMUM MASS SUPPORTABLE BY TWIN FLEXIBLE CORD
0.75	6	6	3
1	10	10	5
1.5	16	16	5
2.5	25	20	5
