Electric Hook Up Copper Armoured Cable , 300V Internal Wiring PVC Armoured Cable
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Rated Voltage: | 300 V | Temperature Rating: | 80°C |
|---|---|---|---|
| Insulation Colour: | Black Blue Brown Green Grey Yellow White Violet Pink | Conductor: | Tinned Or Bare, Stranded Or Solid Copper |
| Insulation: | PVC (Polyvinyl Chloride) |
300V Hook Up Wire PVC Electrical Cable Standard UL758 UL1581 VW-1
APPLICATION
For general purpose internal wiring of electronic and electrical equipment, where exposed to oil at a temperature not exceeding60°C or 80°C. Uniform insulation thickness of wire to ensure easy stripping and cutting. Resistant to acids, alkalis, oils,moisture and fungi.
CABLE STANDARDS
UL 758, UL 1581, CSA C22-2, UL VW-1, CSA FT1
DIMENSIONS
| Size | CONDUCTOR TYPE | CONDUCTOR | INSULATION | MAX RESISTANCE AT 20°C | MIN INSULATION RESISTANCE AT 20°C ohms/km |
DIELECTRIC STRENGTH AC 1MIN V |
|||
| SPEC AWG |
NO. mm |
NOMINAL DIAMETER mm |
NOMINAL THICKNESS mm |
NOMINAL DIAMETER mm |
|||||
| 18AWG | Overall Tinned | 18 | 7/0.404 | 1.21 | 0.41 | 2.03 | 23.2 | 15 | 1500 |
| 20AWG | 20 | 7/0.321 | 0.96 | 0.41 | 1.78 | 34.2 | 15 | 1500 | |
| 22AWG | 22 | 7/0.254 | 0.76 | 0.41 | 1.58 | 54.8 | 15 | 1500 | |
| 24AWG | 24 | 7/0.203 | 0.61 | 0.41 | 1.43 | 86 | 15 | 1500 | |
UL Listed.
